Product Description
8-channel CVBS input, 8-channel audio input.
Dual streams output H.264 format, Audio: MP3, AAC, G.711 format.
Configuration could be freely adjusted according to the need.
Support HTTP / RTSP / RTP/ TCP / RTMP / FLV/ UDP / ONVIF / HLS protocols.
Red indicator: power. Yellow: Streaming status. Green: Network
- Resolution: 720*576i/720*576p /640*480i 640*320,320*240etc
- Supports WINDOWS/ LINUX/MAC OS
- Support RTSP/ RTP/ RTMP/ FLV/ HTTP/ ONVIF/ HLS/ UDP unicast and multicast protocol
- Support Main TS stream and the sub TS stream use in different network protocols for transmission
- Encoding level: 1, 2, 3, 4 and 5 (the higher the level, the larger of the code flow fluctuation ratio )
- Coding Standard: Base line profile/ main profile/high profile, H.265 main profile:
- Audio: MP3, AAC, G.711, sampling rate: 32000,44100, etc, encoded audio bit rate: 48K, 64K, 96K, 128K, 160K, 192K, 256K
- Video bitrate Control: CBR / VBR 16KBIT / S ~ 12MBIT / S
- Video packaging: A mode: FFMPEG, B mode: VLC
- Transmission: TCP, UDP, 100M/ 1000M (RJ45 Duplex network port)
- Support WEB access in Chinese/ English, passwords change, WAN remote management (WEB)
- Support Text/ image OSD, images superimposing.
- Adjustable coordinates: 1920×1080; the font size: 8 to 72.
- Supports automatically obtain IP (DHCP), support One-key recovery, upgrade and remote maintenance.
- Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
- Support build-in or external audio input, support left and right sound channel, Support audio gain, turn volume individually.
- Support encoding without video signal;
- Take effect immediately when applied the settings, don’t need to restart.
- Support one-key recovery to default setting.
- Low power consumption design.
Specification
Product model |
H3408B 8channel CVBS SD encoder |
Input |
8-channel AV/CVBS input,
8-channel 3.5MM audio input
|
Output |
1-channel IP signal output |
Video |
Input resolution |
720*576i/720*576p /640*480i 640*320,320*240etc |
Coding standard |
H.264 |
Coding level |
H.264 BASELINE PROFILE
H.264 MAIN PROFILE
H.264 HIGH PROFILE
|
Encoded size
|
640*360~1920*1080 |
Video bit rate |
Rate control: CBR/VBR 16KBIT/S~12MBIT/S |
Video frame rate |
5-30 FPS |
OSD |
Text, Image |
Audio |
Input selection |
8 channel AV
8 channel 3.5MM independent audio
(Support audio gain)
|
Audio coding |
AAC/MP3/G.711 |
Audio bit rate |
64Kb/s~384Kb/s |
Sampling rate |
32000、44100,48000 etc |
IP
output
|
1 RJ 100M / 1000M adaptive Ethernet port, dual-stream( H.265/264 TS stream) |
System |
Network protocol |
Supports HTTP, RTSP, RTMP, UDP, ONVIF,FLV,HLS multicast, unicast |
Configuration management |
User interface, remote upgrade, Andriod /IOS APP, multiple management platform |
The common use |
Power supply |
220V |
power consumption |
<40W |
Size |
300mm *440mm * 43mm(length*width*height) |
Operating temperature |
-20℃+ 60℃ |
Working humidity |
<90%,Non-condensing |
Weight |
3.5KG |
Haiwei reserves the right to adjust the product parameters, if you have any questions please contact us. |
