Product Description
1-channel HD HDMI input, 2-channel AHD CVBS input,1-channel audio input.
Dual streams output.H.264 format, Audio: MP3, AAC, G.711 format.
Configuration could be freely adjusted according to the need.
Support HTTP / RTSP / RTP/ TCP / RTMP / FLV/ UDP / ONVIF protocols.
Red indicator: power. Yellow: Streaming status. Green: Network
- The embedded hardware encoding
Support 1920x1080p/1920x1080i/1280x720p/720*576i/720*576p/640*480i/640*320/320*240 solutions (Can customized))
- Support H.264 BASELINE PROFILE / MAIN PROFILE / HIGH PROFILE
- Support multiple devices display on a computer at the same time
- Support network directly connected, don’t need match HD collection card.
- Support Network interface full-duplex mode 1000M
- 1 channel HDMI input, 2 channel CVBS input, 1 channel audio interface 3.5MM independent input, support SDI / VGA / CVBS convert to HDMI input, Support audio gain ,be able to turn volume individually
- Support up to 720P,1080P HD video input
- Support RTSP/RTP/RTMP/HTTP/ONVIF/UDP/HLS unicast and multicast protocol (RTMP support adding users and changing passwords), Support DHCP/,ONVIF protocol, support HD Blue-ray
- Compatible with Wowza/FMS/RED5 streaming media server etc, work in with streaming media server to push the streaming , to achieve a live streaming
- Support Main TS stream and the sub TS stream use in different network protocols for transmission (Multi-rate multi-protocol support)
- Rate Control CBR / VBR 16KBIT / S ~ 12MBIT / S
- Video packaging: A mode: FFMPEG, B mode: VLC
- Supports streaming resolution custom output settings
- Transmission: TCP, UDP, 1000M (RJ45 Ethernet port duplex)
- Support streaming add watermark (OSD), XY axis, the font can be set;
- Transmission: TCP, UDP, 1000M (RJ45 Duplex network port)
- Support WEB access in Chinese/English, passwords changing, WAN remote management (WEB)
- Support DHCP gaining IP automatic ,support One-key recovery, upgrade and remote maintenance
- Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
- Support build-in or external methods , support left and right sound channel , Support audio gain ,be able to turn volume individually
- Support coding without video signal;
- Complete the setting effect immediately, don’t need to restart
- Support one-key recovery of the default configuration
- Support set-top box decoder
- The low power consumption design
Specification
Product model |
H3112B 1*HDMI+2*AHD CVBS encoder
|
Input |
1 HDMI input, 2 channel CVBS input, 2 channel 3.5 audio input |
Output |
1 channel IP output |
Video |
Input resolution |
1920×1080/1680×1050/1280×720/1600×1200/960×540/720*576/704*576 And other conventional resolution |
Coding standard |
H.264 / H.265 |
Coding level |
H.264 / H.265 BASELINE PROFILE
H.264 / H.265 MAIN PROFILE
H.264 / H.265 HIGH PROFILE
|
Encoded size
|
320*240~1920*1080(Can customize) |
Video bit rate |
Rate control :CBR/VBR 16KBIT/S~12MBIT/S |
Video frame rate |
5-60 Fps |
OSD |
Character ,images |
Audio |
Input selection |
1 channel embedded audio hdmi, 2 channel AV,1 channel 3.5MM independent audio(Support audio gain) |
Audio coding |
AAC/MP3/G711 |
Audio bit rate |
64Kb/s~384Kb/s |
Sampling rate |
32000、44100 48000etc |
IP
output
|
1 RJ 100M / 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol |
System |
Network protocol |
Supports HTTP, RTSP, RTMP, UDP, HLS multicast, unicast |
Configuration management |
Support IE configuration, remote upgrade |
The common use |
Power supply |
12V~2A |
power consumption |
5W |
Size |
100mm *118mm * 40mm(length*width*height) |
Operating temperature |
-20℃+ 60℃ |
Working humidity |
<90%,Non-condensing |
Weight |
0.3KG |
Our company reserves the right to adjust the product parameters, if you have any questions please contact us to check |
