Z1400 Series Full HD PTZ Camera

Want create site? Find Free WordPress Themes and plugins. 1.Z1400 employs 1/2.9 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 30fps. 2.3X and 10X optical zoom lens for selection. 3.Advanced and

Image Sensor : 1/2.9 Inch High Quality CMOS Sensor

Effective Pixels : 2.07MP, 16

Low Illumination : 0.5Lux (F1.8, AGC ON)

WDR : OFF/ Dynamic Level Adjustment

Video Adjustment : Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve

Phone:+86 18926159746 020-36164006

1.Z1400 employs 1/2.9 inch high quality CMOS sensor. Resolution is up to 1920×1080 with frame rate up to 30fps.
2.3X and 10X optical zoom lens for selection.
3.Advanced and leading algorithm enables the camera auto focus fast and accurately.
4.Low noise CMOS ensures super high SNR image. The advanced 2D/3D noise reduction technology reduces the noise while ensuring high image clarity.
5.Support VISCA, PELCO-D, PELCO-P protocols; Support automatic identification protocols.
6.RS485, RS232 in & out, support cascade connection.
7.Support low-power sleep/wake up, the consumption is lower than 400mW under sleep mode
8.Up to 255 presets (10 presets for IR remote control)

Relate series,click for more info

Specification

Model No.	Z1400-03		Z1400-10
Camera Parameter
Image Sensor	1/2.9 Inch High Quality CMOS Sensor
Effective Pixels	2.07MP, 16:9
Video Format	1920×1080P@30 fps/25fps; 1280×720P@30fps/25fps; 1024×576P@30fps/25fps; 960×540P@30fps/25fps; 800×448P@30fps/25fps; 640×360P@30fps/25fps; 320×176P@30fps/25fps
Optical Lens	3X Optical Zoom f＝3.35mm-10.05mm		10X Optical Zoom f＝4.34mm-41.66mm
View Angle	30°～85°		8.8°～ 68.8°
Iris	F1.7-3.0		F1.85 – F2.43
Digital Zoom	10X
Low Illumination	0.5Lux (F1.8, AGC ON)
DNR	2D﹠3DDNR
White Balance	Auto / Manual/ One Push//3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
Focus	Auto / Manual/ One Push
Electronic Shutter	Auto / Manual
BLC	On/Off
WDR	OFF/ Dynamic Level Adjustment
Video Adjustment	Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR	>50dB
Interface and Protocol
Video Output	USB2.0. Type A
Video Compression	H.265, H.264, MJPG
Control Port	RS232 in & out, RS485
Control Protocol	VISCA/Pelco-D/Pelco-P
Power Supply	HEC3800 Outlet (DC12V)
USB characteristics
Support operating system	Windows 7,Windows8, Windows10, Mac osx ,Linux
Video Compression	H.265, H.264, MJPG
USB communication protocol	UVC
PTZ Parameter
Pan/Tile Rotation	-170°~+170°, -30°~+90°
Pan/Tile Controller Speed	0.1~60°/Second, 0.1~30°/Second
Preset Speed	Pan:60°/Second, Tilt: 30°/Second
Preset Numbers	255 Presets (10 presets on IR Remote)
Other Parameter
Working Voltage		12V
Working current		0.25A(max)
Power Consumption		2.5W(max)
Storage Temperature		-10℃～+60℃, 20%～95%
Working Temperature		-10℃～+50℃, 20%～80%
*Dimension(WHD)*		156.8mm×112.6mm×139.5mm
Weight		1KG
Usage		Indoor Only
Package		Power Supply, USB2.0 Cable, Remote Controller, User Manual
Accessories Optional		Mount (Extra Cost)
