R3 is professional thermal camera，Support 1 channel CVBS output，USB power .Support 5 pseudo -color modes, support electron magnification, and support a variety of lighting algorithms. Product introduction
R3 is professional thermal camera，Support 1 channel CVBS output，USB power .Support 5 pseudo -color modes, support electron magnification, and support a variety of lighting algorithms. Product introduction :
Phone:+86 18926159746 020-36164006
Product introduction：
R3 is professional thermal camera，Support 1 channel CVBS output，USB power .Support 5 pseudo -color modes, support electron magnification, and support a variety of lighting algorithms. Product introduction
Parameters：
|
Model |
R3 Thermal camera |
|
|
Pixel Space |
17μm |
|
|
Detector type |
Oxidation |
|
|
Lens |
7,9.5,12.3,18,19mm and other lenses are available, the default 9.5mm lens |
|
|
Video |
Resolution |
640*512 |
|
Lighting algorithm |
Scene adaptive lighting algorithm, brightness, and contrast can be adjusted |
|
|
Palette |
Multi -pseudo color adjustable（default pseudo colors，Including Black hot、 White hot、Hot metal pseudo、Rainbow pseudo、Green pseudo） |
|
|
Image Processing |
Non -uniform correction, smooth image smooth function, enhancement of image details, digital filter noise reduction |
|
|
Output |
CVBS |
|
|
FPS |
50 |
|
|
Data interface |
UART（3.3V） |
|
|
Power |
Power range |
3~5VDC |
|
Typical power supply |
5V DC |
|
|
Power consumption |
1W |
|
|
Size |
72mm x 28mm x 28mm |
|
|
working temperature |
-40℃+ 60℃ |
|
|
Working humidity |
<90%，No condensation |
|
|
Weight |
0.027KG |
|
|
Our company reserves the right to adjust the product parameters. If you have any questions, please contact us to check |
||
